Antennas
Choosing a reliable antenna technology for your device is mission-critical. You can search our catalog for the antenna that meets your technology, frequency, and mounting needs.
Antenna
BAR mXTEND™ (NN02-232)
KEY SELLING POINTS
- Top performance: Top multiband IoT performance in a ultracompact form factor - 10.0 mm x 3.2 mm x 3.2 mm
- Multiband & Multiport: 2G/3G/4G/5G, LTE-M, and NB-IoT applications
- Global reach: Through multiband performance (compatible with multiple regional standards)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Small tracking devices, IoT sensors and IoT cellular/ISM modules, mobile devices
Antenna
CUBE mXTEND™ (NN02-250)
KEY SELLING POINTS
- Smallest footprint: Multiband cellular IoT performance in the smallest footprint - 5.0 mm x 5.0 mm x 5.0 mm
- Multiband & Multiport: 2G/3G/4G/5G, LTE-M, and NB-IoT applications
- Global reach: Through multiband performance (compatible with multiple regional standards)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Small tracking devices, IoT sensors and IoT cellular/ISM modules, mobile devices
Antenna
ALL mXTEND™ (NN02-220)
KEY SELLING POINTS
- High Performance: A global cellular antenna for IoT and mobile devices with a high performance in the subGHz frequency range
- Multiband: All cellular bands covered - 2G/3G/4G/5G and NB-IoT/LTE-M applications in a 24.0 mm x 12.0 mm x 2.0 mm antenna package
- Global reach: Through multiband performance (worldwide standards compatible)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Smart metering, smart city sensors, automotive
Antenna
DUO mXTEND™ (NN03-320)
KEY SELLING POINTS
- Multipurpose: Multiband and multi-RAT IoT chip antenna component with two independent ports
- Smallest clearance: No clearance beyond the antenna footprint
- Miniature: Small form factor of 7.0 mm x 3.0 mm x 2.0 mm
- Best for combining: One or more of GNSS, Bluetooth, UWB and 5G applications
- Versatile: Dual mounting on device corner or center edge
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: tracking devices, wearables, gaming devices, IoT-5G modules
Antenna
ONE mXTEND™ (NN02-201)
KEY SELLING POINTS
- Smallest volume: Multiband cellular/ISM IoT performance in the smallest volume form factor - 7.0 mm x 3.0 mm x 1.0 mm
- Multiband: 2G/3G, NB-IoT/LTE-M, 5G, ISM, and Wi-Fi 6E applications
- Wide reach: Multi regional product (compatible with multiple regional standards)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: WiFi-6E devices and IoT entry level products such as miniature trackers, IoT sensors, wearables and alike
Antenna
RUN mXTEND™ (NN02-224)
KEY SELLING POINTS
- Top performance: Top multiband IoT performance in a ultracompact form factor - 12.0 mm x 3.0 mm x 2.4 mm
- Multiband & Multiport: 2G/3G/4G/5G, LTE-M, and NB-IoT applications
- Global reach: Through multiband performance (compatible with multiple regional standards)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Small tracking devices, IoT sensors and IoT cellular/ISM modules, mobile devices
Antenna
TRIO mXTEND™ (NN03-310)
KEY SELLING POINTS
- Top performance: Top multiband worldwide sub-6GHz cellular/IoT performance in a multi-RAT and 3 independent port antenna component
- Multiband & Multiport: All cellular/ISM bands: 2G/3G/4G/5G and NB-IoT/LTE-M applications with additional GNSS, Bluetooth, Wi-Fi 6E, UWB simultaneously
- Versatile: Triple radio architecture in a single, small and ultra-slim antenna package - 30mm x 1.0mm x 3.0mm
- Global reach: Through multiband performance (worldwide standard compatible)
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Best for top performing compact tracking devices, IoT sensors, IoT cellular/ISM modules, and mobile devices
Antenna
NANO mXTEND™ (NN02-101)
KEY SELLING POINTS
- Multipurpose: Bluetooth and Wi-Fi (2400 – 2500MHz)
- Smallest clearance: 5 mm x 5 mm
- Miniature: Smallest Virtual AntennaTM form factor of 3.0 mm x 2.0 mm x 0.8 mm
- Versatile: Can be mounted either on the device corner or on the center edge
- Reliability: Off-the-Shelf standard product, no antenna part customization (electronic optimization)
- Use cases: Smart home, tracking devices, wearables, gaming devices, IoT modules
Antenna
1004795 – On Board 5G / LTE / LTE-M / NB-IoT FR4
KEY SELLING POINTS
- Supports 5G, LTE, LTE-M, and NB-IoT frequency bands
- Active Band Switching option available
- Tuning capabilities for efficiency optimization
- High efficiency
- Low profile
- SMD
- Mirror version available for optimum performance (P/N 1004796)
- Mechanical robustness
Antenna
1004796 – On Board 5G / LTE / LTE-M / NB-IoT FR4 (mirror)
KEY SELLING POINTS
- Supports 5G, LTE, LTE-M, and NB-IoT frequency bands
- Active Band Switching option available
- Tuning capabilities for efficiency optimization
- High efficiency
- Low profile
- SMD
- Mirror version of P/N 1004795 for optimum performance
- Mechanical robustness
Antenna
LSP69001299TR – On Board Internal LTE / LTE-M / NB-IoT FR4
KEY SELLING POINTS
- Supports LTE, LTE-M, and NB-IoT frequency bands
- Optimized for small PCB sizes
- Central feed
- Low profile
- SMD
- Mechanical robustness
Antenna
M620720 – On Board ISM 868 & 915 MHz Ceramic
KEY SELLING POINTS
- Supports ISM frequency bands
- IMD technology
- Low profile
- Small footprint
- SMD
Antenna
9000046-XLPDNB – External ISM
KEY SELLING POINTS
- Supports ISM frequency bands
- Vertical polarization
- SMA male connector
- Black color
Antenna
1001039 – On Board GPS Ceramic Patch
KEY SELLING POINTS
- Supports GPS band
- Circular polarization (R.H.C.P)
Antenna
P822601 – On Board 5G / LTE / LTE-M / NB-IoT FR4
KEY SELLING POINTS
- Supports 5G, LTE, LTE-M, and NB-IoT frequency bands
- Tuning capabilities for efficiency optimization
- High efficiency
- Low profile
- SMD
- Mirror version available for optimum performance (P/N P522306)
- Mechanical robustness
Antenna
P822602 – On Board 5G / LTE / LTE-M / NB-IoT FR4 (mirror)
KEY SELLING POINTS
- Supports 5G, LTE, LTE-M, and NB-IoT frequency bands
- Tuning capabilities for efficiency optimization
- High efficiency
- Low profile
- SMD
- Mirror version of P/N P522601 for optimum performance
- Mechanical robustness
Antenna
1002289F0 series – Off Board LTE / LTE-M / NB-IoT FPC
KEY SELLING POINTS
- Supports all LTE, LTE-M, and NB-IoT frequency bands
- Off-board with cable and U.FL compatible connector
- Compact size
- Different cable lengths available
Antenna
1002089 – Off Board LTE / LTE-M / NB-IoT PCB, SMA Connector
KEY SELLING POINTS
- Supports all LTE, LTE-M, and NB-IoT frequency bands
- Off-board with SMA connector
- High efficiency
- Perfect for MIMO applications
Antenna
1002436 – On Board LTE / LTE-M / NB-IoT Vertical FR4
KEY SELLING POINTS
- Supports all LTE, LTE-M, and NB-IoT frequency bands
- Tuning capabilities for efficiency optimization
- High efficiency
- Narrow footprint – small keep out area
Antenna
X9000984 series – External EU LTE / LTE-M / NB-IoT
KEY SELLING POINTS
- Supports LTE EU, LTE-M, and NB-IoT frequency bands
- Vertical polarization
- Hinged for 2 positions
- SMA or RP-SMA male connectors available
- Black or white color available
